Pain Relief 160 LED Red Light Therapy Belt IRW-002
Product Description: IRW-002 160 LED High-Power Therapy Belt
It offers a non-invasive way to support the body’s natural processes, such as aiding weight management goals by improving circulation and triggering the release of fatty acids from fat tissue (lipolysis). Its design also makes it ideal for post-workout recovery and relieving muscle inflammation.
IRW-002 Key Features & Benefits
160 High-Density LEDs (660nm & 850nm)
Utilizes quality SMD 5050 3-in-1 chips delivering an optimized blend of Red and Near-Infrared light (1:2 ratio) for focused and effective therapy.
High Power Irradiance (>130 mW/cm²)
Robust light energy output ensures sufficient power reaches target tissues for significant therapeutic effects, meeting professional requirements.
Full-Featured Controller
Offers comprehensive treatment customization: adjustable timer (5-30 mins), 5 intensity levels (P1-P5, 5W-22W), pulse modes (10Hz/40Hz/Steady), and wavelength selection (Red only/NIR only/Both).
Supports Weight Management & Body Contouring
Promotes circulation, triggers fatty acid release from fat cells (lipolysis), and helps reduce the appearance of cellulite as part of a healthy lifestyle.
Accelerates Recovery & Relieves Pain
Reduces inflammation, promotes natural painkiller production, relaxes muscles, speeds post-workout recovery, and alleviates various aches and pains.
Safe & B2B Partnership Ready
Non-invasive and EMF-free. As the manufacturer, we offer competitive wholesale pricing for the 160 LED red light therapy belt, reliable quality assurance (1-Year Warranty), and OEM/ODM customization services.
Technical Specifications – IRW-002
| Parameter | Specification |
|---|---|
| Model No. | IRW-002 |
| Dimensions (L*W*T) | 500 x 200 x 7 mm (19.69″ x 7.87″ x 0.28″) |
| LED QTY / Type | 160 Diodes (SMD 5050, 3 chips in 1: 1x660nm + 2x850nm per diode) |
| Wavelengths | 660nm : 850nm (Chip Ratio 1:2) |
| Power Consumption (Adjustable P1-P5) | 5W / 9W / 13W / 17.5W / 22W (±5%) |
| Irradiance (@0in / 0cm) | >130 mW/cm² |
| Controller Features | Timer (5-30min), Intensity (P1-P5), Pulse (10Hz/40Hz/Steady), Wavelength Select (R/NIR/Both) |
| Temperature (Surface, approx. P1-P5) | Approx. 98°F – 110°F (36.7°C – 43.3°C) |
| Input Voltage | DC 12V (Adapter Input: AC 100-240V) |
| Beam Angle | 120° |
| Net Weight (Device only) | 0.30 kg (0.66 lbs) |
| Housing Material | Fabric |
| EMF Emission (@0in) | 0 µT (Negligible / EMF-Free) |
| Rated Lifespan | >50,000 hours (Expected) |
| Warranty | 1 Year (Manufacturer) |
How IRW-002 Works
- 660nm Red Light: Primarily absorbed by skin layers, helping to promote collagen production, improve surface skin conditions, and aid wound healing.
- 850nm Near-Infrared (NIR) Light: Penetrates deeper into tissues, helping reduce inflammation, alleviate deeper muscle and joint discomfort, accelerate recovery, enhance cellular energy (ATP), improve circulation, and support lipolysis.
By delivering both wavelengths at a high intensity of >130 mW/cm² with the density of 160 LEDs, the IRW-002 provides focused and efficient therapeutic benefits to the target area.
What’s Included with IRW-002
1x IRW-002 Red Light Therapy Belt (Device)
1x Controller with Display
1x USB Power Cable
1x AC Power Adapter (100-240V Input)
1x User Manual
Quality Assurance & Certifications (IRW-002)
Manufacturer’s Quality Commitment
The IRW-002 is manufactured in our ISO-certified facility under stringent quality control processes to ensure reliability and consistency. The device is EMF-free. We back this model with:
1-Year Manufacturer’s Warranty
Your Questions Answered
Yes, as the original manufacturer, we offer flexible OEM/ODM services including logo printing, packaging design, and custom wavelength configurations. We welcome inquiries from distributors, clinics, and wellness brands.
Absolutely. It is EMF-free, non-invasive, and operates within clinically studied safe wavelengths. The belt includes an intelligent controller with timer, intensity levels, and wavelength settings—suitable for professional or supervised personal use.
Yes. The IRW-002 delivers high-intensity red (660nm) and near-infrared (850nm) light to stimulate lipolysis (fat breakdown), improve microcirculation, and enhance lymphatic drainage. When used consistently as part of a healthy lifestyle, it may support body contouring goals.
