IRP010-03L Large Red Light Therapy Panel (900W)
Product Description: IRP010-03L
Packed with 1920 high-intensity LEDs delivering optimized Red (660nm) and Near-Infrared (850nm) wavelengths, the YL-IRP010-03L achieves exceptional irradiance levels exceeding >150 mW/cm² at 6 inches. This ensures deep light penetration across broad areas like the full back, torso, or legs, promoting faster recovery, reduced pain, and enhanced cellular function. Its significant size and power make it a highly efficient 900w red light therapy panel for commercial settings.
Command this powerful panel with ease using the full suite of smart controls: an intuitive Touch Panel, a convenient Remote, hands-free Voice Commands, and the versatile Tuya Smart App. Precisely adjust session parameters like duration, intensity (dimming), wavelength mix, and pulsing options to create tailored protocols for diverse client needs, maximizing the benefits of this large red light therapy panel.
Key Features & Benefits
Powerful 900W LED Class:
Engineered for maximum therapeutic dosage, suitable for demanding professional applications requiring high energy output.
High Irradiance for Deep Penetration (>150mW/cm² @ 6″):
Utilizing 1920 high-intensity LEDs, this panel achieves high energy density (>150mW/cm² @ 6″, >200mW/cm² @ 3″) with optimized Red (660nm) & NIR (850nm) light for maximal therapeutic effect.
Advanced Smart Control Suite (Touch, Remote, Voice, App):
Provides ultimate operational flexibility. Use the intuitive touch panel, handy remote, convenient voice commands (e.g., “Hello Panel, Dimming”), or the powerful Tuya Smart App for complete control.
Deep Customization via Tuya App:
Unlock personalized therapy protocols. Adjust Red/NIR intensity (40-100%), set pulse frequencies (up to 99Hz), create custom scenes, and utilize pre-programmed Smart Modes.
Multiple Therapy Modes (Normal, Pulse, Breathing):
Offer varied treatment experiences beyond continuous light, including pulsing (1Hz: 100%-40% brightness) and breathing (0.5Hz: 100%-40% brightness) modes accessible via remote/panel.Targeted Light Delivery (30° Beam Angle):
30-degree lens beam angle focuses the light from the 1920 LEDs for efficient and targeted treatment applications.
Enhanced Cooling System:
Features 6 cooling fans to ensure stable operation and longevity (>30,000 hours) even under demanding use.
Low EMF & Modular Potential:
Designed for user safety and comfort with minimal electromagnetic field emissions.
Technical Specifications – IRP010-03L Red Light Therapy Panel
| Parameter | Specification |
|---|---|
| Model No. | YL-IRP010-03L |
| LED Power Class | 900W |
| Power Consumption | 540W (±5%) |
| LED Quantity | 1920 pcs |
| Input Voltage | AC 100-240V, 50/60Hz |
| Irradiance (@6in / 15cm) | >150 mW/cm² |
| Dimensions (LxWxH) |
35.98″ x 19.09″ x 2.17″
|
| Cooling Fans | 6 fans |
| Beam Angle | 30° |
| Rated Lifespan | >30,000 hours |
| Warranty | 1 Year |
What’s Included with IRP010-H06T Red Light Therapy Panel
- IRP010-03L Red Light Panel(x1)
- Power Supply (x1)
- Remote Controller (x1) (Batteries not included)
- Stainless Steel Safety Chain (x2)
- Rope Ratchet (Lanyard) (x2)
- Protective Goggles (x1)
- User Manual (x1)
Package contents may be subject to change. Please refer to the final product packaging.
Compatible Accessories (Sold Separately)
- Floor Rolling Stand (Compatible with IRP010-03L/05L/06L )
*Note: Specific accessories may vary slightly by region or batch. Please refer to the actual product received.Please verify accessory compatibility before purchase.
Quality Assurance & Certifications (IRP010-03L)
-
Our Commitment to Quality
At BoYuanYang we stand behind the quality and performance of our professional red light therapy solutions. The IRP010-03L is built with high-quality components and rigorous manufacturing standards to ensure reliable operation and lasting value for your business.
1 Year Manufacturer’s Warranty
We proudly back the IRP010-03L with a comprehensive 1-year warranty against manufacturing defects. Please refer to our warranty policy or contact us for full details.
Your Questions Answered
You can place a wholesale order by contacting our sales team to request a detailed quote and discuss your specific requirements. After confirming order quantity, pricing, and delivery timeline, we will process your order, conduct quality inspections, and arrange shipping. We also provide ongoing technical support to ensure smooth cooperation.
The YL-IRP010-03L is a powerful 900W LED class panel equipped with 1920 high-intensity LEDs delivering optimized 660nm red light and 850nm near-infrared light. It achieves high irradiance levels exceeding >150 mW/cm² at 6 inches, with a focused 30° beam angle for efficient treatment. The panel features advanced smart controls including touch panel, remote, voice commands, and Tuya Smart App integration. It includes 6 cooling fans to ensure stable operation and has a rated lifespan of over 30,000 hours.
The package includes the red light therapy panel, power supply, remote controller (batteries not included), stainless steel safety chains, rope ratchets, protective goggles, and user manual. The product comes with a 1-year manufacturer’s warranty to ensure quality and reliability for professional use.
